MEANWELL UHP Series PFC LED Switching Power Supplies – 5V / 12V / 24V / 36V / 48V DC Output, 200W / 350W / 500W / 750W / 1000W, AC90–264V Input, UL / CE Certified
MEANWELL UHP Series PFC LED Switching Power Supplies – 5V / 12V / 24V / 36V / 48V DC Output, 200W / 350W / 500W / 750W / 1000W, AC90–264V Input, UL / CE Certified
Regular price
$93.99 USD
Regular price
Sale price
$93.99 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
About this item
- MEANWELL UHP Series PFC Power Supply: Professional UHP series LED switching power supply with active PFC design, providing reliable DC output for industrial equipment, LED systems, and demanding low-voltage applications.
- Wide Voltage & Power Selection: Available in 5V, 12V, 24V, 36V, and 48V DC output options with power ranges from 200W up to 1000W (model dependent) to match different system requirements.
- Narrow Metal Case Design: Compact narrow-profile metal housing provides space-saving installation while maintaining a professional structure for industrial and commercial power applications.
- High Efficiency Cooling System: Built-in forced air cooling fan and optimized thermal design help maintain stable operation during continuous high-power use with efficiency up to 96% (model dependent).
- Industrial Protection & Certified Reliability: Provides short-circuit, overload, over-voltage, and over-temperature protection with UL, CE, TUV, BIS, and EAC certifications available depending on model.
Package Included
| Version | Package Included |
|---|---|
| MEANWELL UHP Series Switching Power Supply |
1 × MEANWELL UHP Series Narrow Switching Power Supply 1 × User Manual |
Order & Logistics
- Lead Time: Usually ships within 1–3 business days from local warehouses.
-
Shipping Note: This series enjoys our Free Shipping Policy for orders over $299.
Local Delivery: Available from local warehouses. Delivery usually takes 3–7 days.
HQ Fulfillment: If local stock is unavailable, products will ship from our headquarters warehouse. Standard delivery takes 9–18 days, while express delivery takes 5–9 days.
Technical Specification
| Specification | Details |
|---|---|
| Product Type | MEANWELL UHP Series PFC Switching Power Supply |
| Series | UHP Narrow Metal Case Series |
| Output Voltage | 5V / 12V / 24V / 36V / 48V DC (Model Dependent) |
| Output Power | 200W / 350W / 500W / 750W / 1000W (Model Dependent) |
| Model / Output Selection | UHP-200-5: DC 5V 40A / 200W UHP-200-12: DC 12V 16.7A / 200W UHP-200-24: DC 24V 8.4A / 200W UHP-200-36: DC 36V 5.6A / 200W UHP-200-48: DC 48V 4.2A / 200W UHP-350-5: DC 5V 60A / 300W UHP-350-12: DC 12V 29.2A / 350W UHP-350-24: DC 24V 14.6A / 350W UHP-350-36: DC 36V 9.75A / 350W UHP-350-48: DC 48V 7.3A / 350W UHP-500-5: DC 5V 80A / 400W UHP-500-12: DC 12V 41.7A / 500W UHP-500-24: DC 24V 20.9A / 500W UHP-500-36: DC 36V 13.9A / 500W UHP-500-48: DC 48V 10.45A / 500W UHP-750-12: DC 12V 60A / 720W UHP-750-24: DC 24V 31.3A / 750W UHP-750-36: DC 36V 20.9A / 750W UHP-750-48: DC 48V 15.7A / 750W UHP-1000-12: DC 12V 80A / 960W UHP-1000-24: DC 24V 42A / 1000W UHP-1000-36: DC 36V 28A / 1000W UHP-1000-48: DC 48V 21A / 1000W |
| Input Voltage | AC 90–264V / DC 127–370V (UHP-1000 Series: AC 90–264V / DC 250–370V) |
| Frequency Range | 47–63Hz |
| Power Factor Correction | Active PFC Design |
| Cooling System | Built-in Cooling Fan (Forced Air Cooling) |
| Efficiency | 90%–96% (Model Dependent) |
| Ripple & Noise | 150–360mVp-p (Model Dependent) |
| Protection Features | Short Circuit Protection / Overload Protection / Over Voltage Protection / Over Temperature Protection |
| Overload Mode | Auto Recovery Protection Mode (Model Dependent) |
| Operating Temperature | -30°C to +70°C |
| Housing Type | Narrow Metal Case |
| Product Dimensions | UHP-200 Series: 194 × 55 × 26 mm UHP-350 Series: 220 × 62 × 31 mm UHP-500 Series: 232 × 81 × 31 mm UHP-750 Series: 237 × 100 × 41 mm UHP-1000 Series: 240 × 115 × 41 mm |
| Safety & Compliance | UL / TUV / CE / BIS / EAC (Model Dependent) |
Applications
- Industrial LED Lighting Systems
- High Power LED Strip Lighting
- LED Display and Signage Equipment
- Automation Equipment
- Electronic Control Systems
- Commercial Low Voltage Power Applications
