850nm 60 LEDs/m DC12V IR LED Light Strip – Night Vision IR for Security Cameras and Security Illumination, SMD2835/SMD5050, IP00/IP65, 5 Meters
850nm 60 LEDs/m DC12V IR LED Light Strip – Night Vision IR for Security Cameras and Security Illumination, SMD2835/SMD5050, IP00/IP65, 5 Meters
Regular price
$79.99 USD
Regular price
Sale price
$79.99 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Package Included
| Version | Package Included |
|---|---|
| SMD2835 850nm 60 LEDs/m Non-Waterproof | 1 × 16.4 ft (5m × 1 Roll) IR LED Light Strip + 1 × Terminal |
| SMD2835 850nm 60 LEDs/m IP65 Waterproof | 1 × 16.4 ft (5m × 1 Roll) IR LED Light Strip + 1 × Terminal |
| SMD5050 850nm 60 LEDs/m Non-Waterproof | 1 × 16.4 ft (5m × 1 Roll) IR LED Light Strip + 1 × Terminal |
| SMD5050 850nm 60 LEDs/m IP65 Waterproof | 1 × 16.4 ft (5m × 1 Roll) IR LED Light Strip + 1 × Terminal |
About this item
- Available in SMD2835 and SMD5050 infrared LED versions with an 850nm wavelength.
- Features 60 LEDs/m density for infrared illumination applications.
- Operates on DC 12V with a 120° beam angle.
- Available in Non-Waterproof and IP65 Waterproof versions.
- Dimmable with compatible LED dimmers.
- Supplied in a 5m (16.4 ft) roll.
- Features self-adhesive backing for easy installation.
- Emits invisible infrared light suitable for medical, industrial, security, and plant growth applications.
Order & Logistics
- Lead Time: Ships within 1–3 business days, occasionally 3–6 business days.
- Packing: Cardboard box.
- Shipping: Ships from local warehouse in 3–7 days if available, or from headquarters warehouse in 9–18 days by standard shipping or 5–9 days by express shipping.
Technical Specification
| Specification | SMD2835 60 LEDs/m | SMD5050 60 LEDs/m |
|---|---|---|
| Wavelength | 850nm | 850nm |
| Light Color | Infrared | Infrared (Invisible) |
| Strip Model | SMD2835-300 | SMD5050-300 |
| LED Type | SMD2835 | SMD5050 Tri-Chip |
| LED Density | 60 LEDs/m | 60 LEDs/m |
| Input Voltage | 12V DC | 12V DC |
| Power Consumption | <8W/m | <12W/m |
| Beam Angle | 120° | 120° |
| Cuttable Section | 3 LEDs / 2" | 3 LEDs / 2" |
| Strip Length | 5m (16.4 ft) | 5m (16.4 ft) |
| Strip Size (W×H) | 8 × 2 mm | 10 × 2 mm |
| PCB Color | White | White |
| Waterproof Options | Non-Waterproof, IP65 | Non-Waterproof, IP65 |
| Dimmable | Yes (Requires Compatible Dimmer) | Yes (Requires Compatible Dimmer) |
Applications
- Medical and Health Applications
- Industrial and Inspection Lighting
- Plant Growth Supplemental Lighting
- Security and Monitoring Systems
- Stage Lighting
- Ambient Illumination
