Package Included
| Version | Package Included |
|---|---|
| SMD2835 660–670nm 120 LEDs/m Non-Waterproof | 1 × 16.4 ft (5m × 1 Roll) IR LED Light Strip |
| SMD2835 660–670nm 120 LEDs/m IP65 Waterproof | 1 × 16.4 ft (5m × 1 Roll) IR LED Light Strip |
| SMD5050 660–670nm 120 LEDs/m Non-Waterproof | 1 × 16.4 ft (5m × 1 Roll) IR LED Light Strip |
| SMD5050 660–670nm 120 LEDs/m IP65 Waterproof | 1 × 16.4 ft (5m × 1 Roll) IR LED Light Strip |
About this item
- Available in SMD2835 and SMD5050 Tri-Chip LED versions with a 660–670nm deep red wavelength.
- Features a high-density design with 120 LEDs/m for bright and uniform illumination.
- Operates on DC 12V with a 120° beam angle.
- Available in Non-Waterproof and IP65 Waterproof options.
- Cuttable every 3 LEDs / 1" (SMD2835) or 6 LEDs / 1" (SMD5050 Dual Row) for flexible installation.
- Supplied in a 5 meter (16.4 ft) roll.
- Features flexible white PCB construction with self-adhesive backing.
- Dimmable with compatible LED dimmers.
- Suitable for therapy lighting, plant growth applications, industrial lighting, and ambient illumination.
Order & Logistics
- Lead Time: Ships within 1–3 business days, occasionally 3–6 business days.
- Packing: Cardboard box.
- Shipping: Ships from local warehouse in 3–7 days if available, or from headquarters warehouse in 9–18 days by standard shipping or 5–9 days by express shipping.
Technical Specification
| Specification | SMD2835 120 LEDs/m | SMD5050 120 LEDs/m |
|---|---|---|
| Wavelength | 660–670nm | 660–670nm |
| Color | Red | Red |
| Strip Model | SDM2835-600 | SDM5050-600 |
| LED Type | SMD2835 | SMD5050 Tri-Chip |
| LED Density | 120 LEDs/m | 120 LEDs/m |
| Input Voltage | 12V DC | 12V DC |
| Power Consumption | <12W/m | <18W/m |
| Beam Angle | 120° | 120° |
| Cuttable Section | 3 LEDs / 1" | 6 LEDs / 1" |
| Strip Length | 5m (16.4 ft) | 5m (16.4 ft) |
| Strip Size (W×H) | 8 × 2 mm | 15 × 2 mm |
| PCB Color | White | White |
| Waterproof Options | Non-Waterproof, IP65 | Non-Waterproof, IP65 |
| Dimmable | Yes (Requires Compatible Dimmer) | Yes (Requires Compatible Dimmer) |
Type of LED & Different Waterproof IP Grade
- Non-Waterproof: Bare strip with self-adhesive backing, suitable for indoor and dry use.
- IP65 Waterproof: Surface covered with protective gel, suitable for areas exposed to sprayed water.
Installation Tips
- Always disconnect power supply before cutting or connecting LED light strips.
- Do not crimp strip tape or bend strips to a radius less than 15mm.
- Do not connect LED strips directly to 120V AC power.
- Apply power to test LED strips before mounting.
How to Power / Control the Strip
- Choose transformer wattage based on the total power consumption of the LED strips.
- Select a transformer with a higher wattage rating than the total strip load for improved reliability.
- Using a higher wattage transformer will not damage the strips and helps extend service life.
- The strip can be controlled using a wall switch or compatible dimmer.
- Multiple strip runs can be controlled using amplifiers and additional power supplies where required.
Applications
- Therapy and Wellness Lighting
- Plant Growth Supplemental Lighting
- Industrial and Inspection Lighting
- Stage Lighting
- Ambient Illumination
